Product Introduction

For the preparation and transfer of various buffers. adjuvants, purification reagents, blockers, etc.

‌• Module design assembly technology,capacity 10~10.000L;

‌• Fully automatic CIP and SIP;

‌• Use upper stirring or bottom stirring device to achieve liquid or liquid mixing ,liquid and solid mixing;

‌• Various feeding methods can meet the requirements of solid power feeding, mother liquor feeding and WFI feeding;

‌• Level measurement or weighting measure is optional, to achieve material auto-metering;

‌• Link pH sensor and acid and alkali pumps to achieve pH adjustment automatically;

‌• Aseptic material transport, the liquid filter on the transfer pipeline enables on-line sterilization or on-line integrity detection;

‌• Equipped with temperature control unit for rapid temperature increase,rapid temperature drop and cryogenic preservation.

Product Advantages

‌• Biological vaccine production line

It is rich in variety, mainly for the production for required culture medium,buffer preparation of vaccines,genetic recombination, monoclonal antibodies.

Aseptic requirements are high, especially aseptic docking before filling.

‌• Water, powder injection, large infusion, diagnostic reagent production line

Many varieties, less residue requirements, high requirements for the sterility of the equipment.

The WFI is automatically added after cooling by the double tube sheet heat exchanger. Achieve material cycle decarburization, automatic sterilization filtration.

‌• Fat emulsion production line

Using elevating stirring, the bottom magnetic stirring device, upper mechanical stirring device, stepless speed regulation. Product emulsification by high shear mixing pump and homogenizer. Hygienic U-tube heat exchangers for material cooling.

‌• Food and beverage production line

Adopt special anti-mixing valve in the industry.Hygienic U-tube heat exchangers for material cooling. The material outlet pipe has a filtering device.
